Lanthanum hexaboride is blue to purple powder of cubic crystal system, which is CaB6 type structure. It is available in sputtering target. LaB6 is hard to dissolve in water and hydrochloric acid. It would decompose when above the melting point. LaB6 is available with powder, polycrystal and monocrystal. It is not transparent, which show light red purple when dry, however show dark red when moisture. There are three methods of producing monocrystal LaB6, zone melting method, flux method and vapor phase method. LaB6 is thermoelectronic emitter. Lanthanum oxide and boron are the raw material.
Lanthanum Hexaboride
Purity:La/RE 99.9% 3N
Particle size:-20~500mesh, 100nm, 50nm, 30nm
| CAS No.:12008-21-8 | EINECS No.:234-531-6 | Molecular Formula:LaB6 | Molecular Weight:203.77 |
| Melting Point:2715℃ | Density:4.76 |
Applications
Lanthanum boride gets wide applications, which successfully apply to radar system in aerospace, electronic industry, instrument, home appliance metallurgy, environmental protection and about twenty military and high tech industry. LaB6 gets many uses in electron industry, which own better field emission property than tungsten(W) and other material. It is ideal material for high power electronic emission cathode. It plays a role in highly stable and high life electron beam, for example electron beam engraving, electron beam heat source, electron beam welding gun and other high performance compents. Monocrystal lanthanum boride is best cathode material for high power tube, magnetic control device, electron beam and accelerator. LaB6 gets wide uses in electron microscope.
